Two-Way Communication
Let workers speed-dial two important contacts directly from the device.
Personal Tracker
TL200
Silent no more, always in focus
Portable Worker Safety Tracker
A lanyard-style worker safety tracker with two-way communication, panic assistance, precise positioning and intelligent power management.
TL200
Core capabilities
Essentials That Matter
Practical control, protection and fleet intelligence—built into one connected device.
LTE & GSM Network
Stable communication through IoT-specific 4G LTE with 2G fallback.
GPS, BDS & GLONASS Positioning
Multiple satellite systems help display accurate locations on the cloud platform.
Panic Button
Enable a worker to request immediate help with one press.
Remote Listen-in
An inconspicuous microphone supports remote awareness around the device.
Multiple Alerts
Receive power-on, shutdown, low-battery, SOS and SIM-change alerts.
TL200 in focus
See the capability. Picture the result.
Product details
Built for the way your fleet works.
A lanyard-style worker safety tracker with two-way communication, panic assistance, precise positioning and intelligent power management.
Two-Way Communication
Let workers speed-dial two important contacts directly from the device.
LTE & GSM Network
Stable communication through IoT-specific 4G LTE with 2G fallback.
GPS, BDS & GLONASS Positioning
Multiple satellite systems help display accurate locations on the cloud platform.
Step Counter
A detected step can wake the device, count movement and upload data to the platform.
Multiple Working Modes
Configure the device for step-count-based or timed tracking.
Panic Button
Enable a worker to request immediate help with one press.
Remote Listen-in
An inconspicuous microphone supports remote awareness around the device.
Multiple Alerts
Receive power-on, shutdown, low-battery, SOS and SIM-change alerts.
Positioning & Location
TechnologyGPS, BDS, LBS, BLE, WiFi
Accuracy<2.5m CEP
Tracking sensitivity–165dBm
Acquisition sensitivity–148dBm
TTFF (open sky)Hot start ≤1sec; cold start ≤32sec
Cellular
Technology4G Cat 1, GSM
FrequencyLTE-FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28; LTE-TDD: B38/B40/B41; GSM: B2/B3/B5/B8
Power
Battery2,000mAh / 3.7V rechargeable industrial Li-Polymer
ModesStep-count-based and timing
Battery lifeUp to 5 days
Interface
LED indicationPower (Red), Notice (Green)
SIMNano-SIM
Memory capacity1000 GPS data entries
Buttons2 functional buttons; 1 panic button
USBMagnetic
AntennasInternal GNSS and Bluetooth
Feature
SensorsAccelerometer
ScenariosPower-on, shutdown, low battery, SOS, SIM change and geo-fence alerts
SpecialtiesSpeaker, microphone
BluetoothBLE 5.0
MountingLanyard
Configuration supportSMS, online command
CertificationFCC, CE
Operating Environment
Temperature–20°C to +60°C
Humidity5% to 95%, non-condensing
IP ratingIP65
Physical Specification
Dimensions105.0 × 62.0 × 13.0mm
Weight81g
TL200 BrochureBrochure coming soon
